All models feature Hawke`s new H7 optics with high zoom ratio, supreme clarity and light transmission.
Supreme accuracy for rifle shooting, driven and hunting applications.
Patented Exposed Zero Lock `N` Stop Elevation Turret
30mm Mono-Tube Chassis
Wide Angle FOV
High Volume Eyebox
100mm Eye Relief
Multi-LED High Intensity Reticle
High Grade, Low Dispersion Crown Glass
21 Layer Fully Multi-Coated Lenses
Zoom Magnification Throw Lever (Removable)
Fast Focus Eyebell With Lock Ring
Supplied With Professional Metal Flip-Up Covers.
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Hawke No-Fault Lifetime Warranty.
Mil Pro (20x) Reticle
Accurate mil spacing on 20x magnification. With half Mil spaced markings extending out to 8 Mil of holdover, the Mil Pro (20x) is a versatile reticle that provides aim points no matter how extreme the distance.
All reticle measurements are Mil spaced and offer 1 Mil, 0.5 Mil and 0.25 Mil brackets for range finding. Every second Mil spacing on the lower section is numbered to ensure quick and easy acquisition of target and ease of reference.
Each cross has a see-through gap, allowing an unobstructed view of the target. The thick outer posts are hollowed to ensure they can be seen at all magnifications, without blocking out too much of the view.
Mil Pro 20x models have additional 1/4 Mil aim points on the center section of the reticle to give even greater precision.
When on 20x magnification, the Mil spaced reticle and 1/10 MRAD turrets make for easy point of aim adjustment. Every 10 clicks on the turret will measure exactly 1 Mil spacing on the reticle, also known as 1 MRAD.
MORE RETICLE INFORMATION
Optical System: System H7
Scope Tube: 30mm
Magnification: 4 - 24x
Objective Lens: 50mm
Reticle: Mil Pro (20x)
Illumination: 6 Levels with Off Positions In-between - Red
Parallax: Side Focus
Focal Plane: SFP (Second Focal Plane)
Lens Coating: Fully Multi-Coated - 21 Layers
Field of View: 28.2 - 4.8ft @100yds - 9.4 - 1.6m @100m
Field of View: 5.4 - 0.9 degrees
Eye Relief: 4in - 102mm
PX/Focus: 15yds - ∞ -14m - ∞
Exit Pupil: 0.49 - 0.08″ - 12.5 - 2.1mm
Turret Type: Zero Lock 'n' Stop
Turret Caps: N/A
Click Value: 1⁄ 10MRAD
Elevation Turret Clicks (max): 22 MRAD
Windage Turret Clicks (max): 22 MRAD
Ocular Type: Locking Fast Focus
Power Selector: Knurled Posi-Grip with Removable Zoom Lever
Length: 14.5″ - 369mm
Weight: 23.4oz - 662g
Pro Flip-Up Covers
4″ Sun Shade
Instruction Manual PDF 2.0MB
