Easy to use. Hard to Beat.
Introducing the all-new Hawke Prism Sights, designed for AR and AK pattern rifles. The 6x36 models feature a Bullet Drop Compens5.56 BDC Dot Reticle
Working with your bullet's trajectory the Tactical BDC - 5.56 reticle, exclusively from Hawke, provides usable aim points for AR-pattern rifles and pistols. The glass etched BDC (bullet drop compensating) reticle features an illuminated center dot and horseshoe for fast target acquisition.
For .223/5.56 and .308WIN, zero can be performed at 50yds for good accuracy out to 200yds. For the best accuracy and proper use of the BDC, zero should be confirmed at 200yds. The BDC will then provide aim points in 100yd increments out to 600yds.
For .300BLK and 7.62x39, zero at 100yds. The BDC will then provide aim points in 75yd increments out to 400yds.ating (BDC) reticle designed to accommodate a variety of ammunition including .223/5.56, .308WIN, .300BLK, and 7.62x39.
Supplied With Low-Profile Mount And Lower 1⁄3 Co-Witness Mount
10 Stage Digital Brightness Control
Exposed 1 MOA Click Turrets
High Quality Aluminium Construction
Fixed Parallax At 100 Yards
Auto Shut Off And Shake Awake
Ideal For Use On ARs And Hunting Rifles
Compatible With Micro T-2 Footprint Mounts
Magnification: 6x
Objective Lens: 36mm
Reticle: 5.56 BDC Dot
Illumination: 10 Stage Digital Brightness (8 Day / 2 Night) - Red
Lens Coating: Multi-Coated - 25 Layers
Mount: Weaver Rail (Lower 1/3 Co-Witness and Low Profile)
Eye Relief: 2.8in - 72mm
PX/Focus: 100yds - 91m
Click Value: 1 MOA
Length: 4.1″ - 104mm
Height: 1.9″ - 48mm
Width; 1.9″ - 47mm
Weight: 9.3oz - 264g
FITTED WITH LOW BASE
Length: 4.1″ - 104mm
Height; 2.2″ - 57mm
Width ; 1.9″ - 47mm
Weight: 10.1oz - 287g
FITTED WITH HIGH BASE
Length : 4.1″ - 104mm
Height: 2.8″ - 70mm
Width: 1.9″ - 47mm
Weight: 10.3oz - 293g
Mounted Height: 1.6″ - 40.4mm
SUPPLIED WITH
Box
Instruction Manual
Lens Cloth
High Mount
Low Mount
Rubber Pro
Honeycomb Sunshade
CR2032 Battery
Torx Key
Nitrogen purged. Shockproof. Waterproof. Fog proof. All caliber rated
Hawke Two Year Warranty
